Temperature controlled cold rooms provide complete climate-controlled environments for optimal food preservation across various industries. These advanced storage solutions maintain precise temperature ranges from +15°C down to -45°C, ensuring perfect conditions for everything from fresh produce to frozen goods.
| Product Explanation: Engineered with high-density insulation panels and advanced refrigeration technology, cold room for food storage deliver reliable performance for restaurants, supermarkets, food processing plants, and agricultural facilities worldwide. The modular design allows for complete customization of dimensions, layout, and specifications to match your specific operational requirements, while maintaining optimal food quality, texture, and nutritional value. |
We need to know this information!
1: What's the dimension of a cold room for food storage: Length×Width×Height by Meter | ||||
2: What kind of goods will load inside? What's the indoor temperature? | ||||
3: What's the industry voltage? |
1. Cold Room Panels For Cold Room
Good waterproof performance Polyurethane cold storage board with moisture and water resistance. The rigid polyurethane has a closed-cell ratio of more than 90% and is a hydrophobic material. It does not increase the thermal conductivity due to moisture absorption, and the wall surface will also seep.
Good sound insulation The porosity of the polyurethane material is stable. It has a closed-cell structure, which has excellent heat preservation performance and resistance to freezing and thawing and sound absorption.
Strong resistance to deformation Strong resistance to deformation, not easy to crack, stable and safe finish.
Fire retardant and high-temperature resistant Polyurethane is a flame-retardant self-extinguishing material after adding flame retardant. Its softening point can reach above 250 °C, and it will only decompose at higher temperatures.
Product Name | PU sandwich panel |
Surface Material | color steel(PPGI), stainless steel, aluminum |
Core material | Polyurethane foam |
PU density | 45±2KG/m3 |
Fire grade | B2 |
Width | standard width 1000mm, maximum 1050mm |
Length | Customized, maximum 11980mm |
Thickness | 50/75/100/150/200mm |
Panels thickness (mm) | Temperature gap between internal-external environment | Height of wall panel (max) | Roof length (max) |
mm | ºC | m | m |
50 | 30 | 3.5 | 2.4 |
75 | 40 | 4.5 | 3.8 |
100 | 50 | 5 | 4.5 |
120 | 60 | 5.5 | 6 |
150 | 70 | 6 | 6.5 |
200 | 90 | 7 | 7.6 |
If there is a pressure gap between the internal environment without wind load, over-length or wind-load need to set steel wall beam. | |||
Tips: the data above is figured out according to 8-10 W / heat flux. | |||
2. Condensing Unit For Cold Room
Unit Cold Room Condensing Condenser Unit Evaporator Equipment For Cold Room
Yangchuan Condensing unit is the optimized combination of efficiency, reliability, easy installation, and sound performance. It is optimized designed and manufactured to reduce installation and maintenance costs, more efficient while making your production even more efficient and less noise impact for the neighborhood.
3. Evaporators For Cold Room
Key Features
Comprehensive Temperature Range: Suitable for various preservation needs including chilling (0°C to +10°C) for fruits and vegetables, freezing (-18°C to -25°C) for long-term preservation, and blast freezing (-25°C to -40°C) for rapid freezing that minimizes ice crystal formation.
Flexible Defrost Systems: Electric, hot-gas, or water defrost options available with automatic cycles that minimize ice accumulation and maintain efficient operation.
Smart Monitoring: Advanced systems with IoT connectivity enable real-time remote monitoring of temperature, humidity, and system performance via computer or mobile devices.
Dimension | Length(m)×Width(m)×Height(m) / FT | |||
Refrigeration unit/Condsenor unit | Famous Brand etc | |||
Refrigeration type/Air cooler/Evaporator | Air-cooled/water-cooled/evaporation cooled | |||
Refrigeration | R22,R404A,R407C,R507a Refrigerant | |||
Defrost Type | Electric defrosting | |||
Voltage | 220V/50Hz,220V/60Hz,380V/50Hz,380V/60Hz,440V/60Hz optional | |||
PU Panel | New material polyurethane insulation panel,45 kg/m³ | |||
Panel thickness | 50mm,75mm,100mm,150mm,200mm | |||
Type of door | Hanged door, sliding door, double swing electric sliding door, truck door | |||
Temp of room | -60°C~+20°C optional/Customization | |||
Fittings | All necessary fittings are included, optional | |||
Place to assemble | Indoor/outdoor(concrete construction building/steel construction building | |||
FAQ
1. Can you customize the cold room for food storage dimension and temperature?
Yes, we can customize the cold room for food storage dimensions and temperature according to your requirements.
Any size will do, if you have no idea, please tell me the total amount of your cargo, and our engineer can design it for you.
