Installation Method Of Refrigerating Compressor Unit In Industrial Cold Room
 Jul 09, 2020|View:116

Installation Method Of Refrigerating Compressor Unit In Industrial Cold Room



1. Condensing units should be installed in high temperature environment, outdoor installation should be installed to avoid direct sunlight or rain awning. The air inlet side of the air-cooled condensing unit should be far away from the heat source. Sufficient space and free air passage should be kept around the unit to avoid air short circuit When the water-cooled condensing unit is installed in the special machine room, the space needed for regular cleaning of the condensers should be reserved, and the cooling and ventilation of the machine room should be ensured. If the system layout or compressor location, environmental temperature and other factors may make the system refrigerant to compressor migration, it is recommended to use the crankcase heater, and in the test run before and long-term shutdown before starting the riding wall compressor for full preheating.

 Installation Method Of Refrigerating Compressor Unit In Industrial Cold Room

2. Condensing unit must be reliably grounded during installation. The power supply and cable of three-phase and five-wire shall be provided with adequate capacity according to the power of the unit, and appropriate protective components such as splitters, fuses and leakage protectors shall be installed, as well as appropriate electrical control system. The installation of electrical installations shall comply with the relevant standards. The type of compressor on the nameplate must be noted for proper connection.



3. Condensing units should be installed horizontally on the machine base which is firm enough and adopt effective shock-proof measures. Before the operation of the unit, the sole spring of the compressor, which is used to absorb the start-up impact of the compressor and reduce the vibration transmission, should be adjusted to the working state. Shock Absorber Tube should be as close as possible to the compressor and installed along the axial direction of the compressor, do not allow shock absorber radial horizontal installation.



4. Condensing unit type, the last letter for the "x" are filled with ester lubricants. Such units shall be installed using special tools such as vacuum pumps, refrigerant filling and recovery equipment, pipe fittings, etc. to prevent Ester oil and mineral oil from contaminating each other.
