What Are The Requirements For The Installation Of Containerized Cold Storage Room
 Feb 11, 2020|View:648

What are the requirements for the installation of the containerized cold storage room? The containerized cold storage room can be assembled in the container and equipped with refrigeration equipment according to the needs of customers' quick freezing capacity. The refrigeration equipment and the heat preservation storehouse are selected in an integrated plan, with compact structure and high refrigeration efficiency. The quick-frozen cold storage usually operates at - 35 to - 40 degrees, with fast refrigeration speed, good freezing effect and high efficiency. The standard IC type container is selected for the cold storage, with the basic structural dimension of 6058mm * 2438mm * 2438mm, equipped with the main temperature area in the middle, built-in shelves, auxiliary temperature area and storage area in the front, generator room and refrigeration unit in the rear. The key components of the refrigeration unit are all world-famous brand products. The unit is reliable in operation, leading in operation, outstanding in function, simple in installation, efficient in power consumption and low in protection rate. The unit is divided into single unit and two-stage low-temperature unit, which are matched sensitively according to the size of the refrigeration system. According to the application requirements of some special occasions, the noise reduction cover can also be customized.

What Are The Requirements For The Installation Of Containerized Cold Storage Room

The main temperature area of the containerized cold storage room adopts the large plate thermal insulation structure, and the scale (length * width * height) is 3100mm * 1920mm * 1740mm. The inner part of the containerized cold storage room is divided into two parts: the upper part is the static pressure air chamber, the lower part is the constant temperature area, with the height of 270mm and 1740mm respectively. The structure of the over static pressure air chamber can produce the stable and uniform laminar flow wind, and the temperature difference in the temperature drop area below is the main temperature drop area; the items to be refrigerated are placed in the constant temperature area. The main temperature zone panel is selected by high temperature curing resin adhesive, and the aluminum profile, rust proof aluminum plate, heat insulation bridge and rigid polyurethane foam material are pasted and restricted to form, with a thickness of 100mm. A ventilation hole is arranged on the top of the rear wall panel, which is connected with the transpiration cabin. The transpiration chamber is equipped with transpiration device of refrigeration system. Its wall structure is the same as that of the main temperature zone, with a thickness of 80mm.
